ADAYO Lighting ODM mini led downlights 24mm height, led spot lights for ceiling 5W 4000K 425lumen, bright light mini recessed downlights new ERP

Amber-B ECO DIY downlight IP44 No-dim 4000k cheap spot light

ECO Downlight Amber B led spotlight ceiling lights hot sales on Amazon, thin led downlights MQO 2000, free sample and instock, delivery fast,ultra thin downlight only 24mm height

Product Specification:
  • Code:926602006057 :
  • Wattage : 4.8W beam angle 38°
  • Luminous : 425lm
  • Colour Temperature : 4000K
  • Colour Rendering : >80
  • Lifespan : 15000hrs
  • Size:Φ87*35mm, cut Φ68mm :
  • Dimable: NA :
Pinterest ADAYO light supply recessed downlight custom LED home lighting and commecial lighting OEM linkedin ADAYO lighting OEM indoor light ip65 home light track light and commecial lighting Facebook ADAYO lighting listed company OEM LED ceiling light and ODM  LED spot light  smart wifi lam Twitter ADAYO lighting offer wifi bulb OEM wifi fire rated downlight custom LED downlight and spot l ADAYO wifi bulb | smart wifi led bulb | wifi led light bulbs
Product Details
Documents download



About this item:

【IP65 waterproof】

The white appearance of the indoor spot lights led  3000k ip44 indoor spot lights led  is soft and elegant. With IP44 protection rating, the ip44 indoor spot lights led  perfect for bedroom, living room, or any room in the house, providing you a bright and comfortable environment.

【Quality lighting】

The mini led downlights for low ceilings, with its luminous flux of 390 lm, replaces the 50W halogen bulb. The colour temperature: 3000K. Glare free. The product has an excellent colour rendering CRI > 80, which allows to obtain colours true to reality. Beam angle of 38 °.  This led spot lights for ceiling PF>0.5,  it is really adjustable downlights for low ceilings for living room with good value.

【Integrated design 】

Integrated design:The led spot lights for ceiling for home cannot be replaced. The  bright light mini recessed downlights is made of PV and aluminum. The acrylic diffuser has better light transmission than other materials. Simple spring fixing for tool-free installation.

【24mm LED spotlight extra flat】

The height of the  mini led downlights is 24mm which allows it to be recessed in ceilings even where space is limited. The outer diameter is 87mm, the recessed hole should be between 68 and 80mm. The fixing system consists of springs that hold the integrated LED in place in its hole.

【High Quality & Safe】

Lifetime: The led spotlight ceiling lights lifetime up to 15000h. Smooth surface, dustproof, rustproof, an ideal choice for modern life!

【Easy To Install】

The integrated design of led spotlight ceiling lights can be directly connected to a voltage of 220V~240V without a transformer, and the installation with side springs effectively prevents leakage between the lamp and the ceiling. Only one mounting hole with a diameter of 68 to 70 mm and a cavity depth of 24 mm is required.

【After-Sales Service】

ADAYO Lighting  promise to provide you with 2 years warranty and lifetime after-sales service of  this ceiling spot lights. If you have any problems or questions during use, please feel free to contact us, we will try our best to solve them within 24 hours.





ADAYO lighting mini led down lights 4.8W C02, 400lm, indoor  spot lights led  features as below:

1. With aluminum heat sink, keep life span 15000hours;

2. Four colors of bezels optinoal: brushed nickel, chrome, silver, black;

3. Size: 87x24mm, cut68mm. It's ultra-slim design for narrow space;

4. Clear light beam angle 38° with no dark spots and has gentle fade to edges for uniform lighting design;

5. Quality SMD 2835, 2700K/3000K/4000K;

6. Triac dim and non dim optional, dimming smoothly;

7. Simple design, comfortable light feeling and easy installation.





Product detail:

ADAYO lighting bright light mini recessed downlights 4.8W with diffirent color bezels choosing detail as below:

1. Driver: Built-in power supply

                Input:220-240v~50/60Hz  Max.0.055A

                PF: >0.5, Prated: 4.8W;

2. Body: Iron and die-cast aluminum heat sink, good heat dissipation, life span 15000Hrs, warranty 3 years, can be installed directly in to the insulation;

3. Light source: SMD2835, CCT3 2700K-3200K-4000K;

4. Ultra-slim design for narrow space

5. Bezel: Four colors of bezels optinoal: brushed nickel, chrome, silver, black.




ADAYO lighting bright light mini recessed downlights  beam angle 38°, with diffirent colors, specification as below:


bright light mini recessed downlights specification

Item Name: DIY ECO downlight AmberB                               Input Voltage(V):                 220-240v ~50/60Hz Max.0.055A
Watt (W): 4.8W Lumen(lm): 400LM
CODE:         926602006057 CRI (Ra>): >80
Certification:                        CE, Rohs             IP Rating: IP44/IP20
Life span: 15000Hrs Beam angle: 38°
Warranty: 2Years CCT: 4000K
Installation: Recessed  spotlight Bezel: Brushed nickel; Chrome; Silver; Black
Driver: PF>0.5 Light source:  SMD2835



ADAYO lighting indoor  spot lights led  4.8W C02, 400lm,  with diffirent colors bezels choosing application as below:

This led spotlight custom save more than 90% of power consumption without losing any brightness.

LED becomes the most popular light source all over the world. This ceiling light made of high quality metal materials, safe and long lifespan.

Perfect for living room, hall, office, store, super market, hotel residence, restaurant, hotel, hall, show room, shop window, assembly room, factory, etc.



The 5w mini led down lights indoor  spot lights is very easy intallation:
